Put the different widths on the drawing
Large openings need a gate-specific drawing and component schedule. A matching mesh panel cannot define the supports, moving joints or locking arrangement of the vehicle gate. “Gate width” can mean a leaf dimension, a distance between posts or the usable opening. Those dimensions are related, but they are not interchangeable. State which measurement is being requested and show the relevant reference points.
For a double-leaf gate, record the two leaves and their meeting arrangement. The required vehicle passage and available space should be assessed with the site layout, rather than inferred from the sum of the leaf widths.
| Drawing field | What it should describe |
|---|---|
| Clear opening | Usable passage dimension and measurement points |
| Leaf arrangement | Single or double leaf, with individual leaf dimensions |
| Opening direction | Direction shown from a stated viewing side |
| Gate height | Relevant level and the relationship to adjacent panels |
| Posts and supports | Post positions and the interfaces requiring project design |
Match the infill without overlooking the frame
358 infill can continue the close-mesh appearance of the fence line. The frame, mesh attachment and gaps around the moving leaves still need their own details. Matching the mesh pattern alone does not establish the performance of the gate assembly.
At each side, show how the fixed fence panel meets the gate post. A line-post detail should not be assumed to suit the post supporting a moving leaf. See 358 fence panels for the adjacent panel and connection specification.
Confirm our gate hardware scope before manufacture
Hinges, latches or locks, drop bolts, stops and holding arrangements each have a role. List the required items, their locations and which party supplies them. A general request for a “complete gate” can otherwise leave different buyers and suppliers with different assumptions.
If another party supplies access-control equipment or a drive, the interfaces need to be reviewed before the gate arrangement is accepted. Equipment attachment, operation and safety assessment are not established by the mesh gate description. FencingWise does not include powered-gate system design as a standard part of material supply.
Review the gate where it will stand
Changes in ground level can affect the opening movement and the gap below a leaf. Show the relevant levels and the intended open and closed positions on the project drawing. Foundation, structural and installation requirements need assessment by the responsible project specialists.
Before approval, reconcile the drawing with the gate schedule and hardware list. If the opening direction or width changes, revisit the affected posts, connections and quantities together.
Custom order specification: 358 mesh vehicle gates
| Order detail | What to define with our team |
|---|---|
| Opening and leaves | Show clear passage, each leaf width, gate height and open and closed positions. |
| Frame and supports | Define the frame, infill attachment, post interfaces and adjacent fence connections. |
| Hardware scope | List hinges, locks, drop bolts, stops and any equipment supplied by others. |
Confirm the gate schedule, ground levels and hardware interfaces before fabrication release. A changed opening or leaf arrangement requires review of the affected posts and connections. Powered operation remains a separate specialist system unless specifically agreed.
Can a double-leaf gate have unequal leaves?
Provide the required passage, preferred active leaf and movement layout. We review the proposed geometry and hardware scope against the project design; the leaf widths and meeting detail must be explicitly approved.
